Features of Hot-dip Galvanized Cable Tray

Craftsmanship and Corrosion Resistance

The process of hot-dip galvanized cable trays involves immersing the rust-removed steel components into molten zinc at approximately 600°C, causing a zinc layer to adhere to the surface of the steel components. The thickness of the zinc layer should not be less than 65μm for sheets under 5mm thick and not less than 86μm for thicker plates, thus achieving the purpose of corrosion resistance. This galvanizing method not only possesses the corrosion-resistant characteristics of electro-galvanizing but also has a strong resistance to corrosion that cannot be compared with electro-galvanizing, making it suitable for various environments with strong acids and alkaline fogs.

Strength and Installation Convenience

Hot-dip galvanized cable trays are made of steel, possessing high strength and rigidity, capable of withstanding heavy loads. In addition, the structural design of hot-dip galvanized cable trays is reasonable, and the construction is convenient, suitable for the cabling needs of various voltage levels.

Appearance Neatness and Durability

Hot-dip galvanized cable trays have a smooth surface, usually silver-gray, with a neat appearance that can maintain aesthetic appeal for a long time. Due to its excellent corrosion resistance and durability, the service life of hot-dip galvanized cable trays can typically reach 20 years or more, making it suitable for long-term use and high-intensity industrial environments.

Application Scenarios of Hot-dip Galvanized Cable Tray

1. Construction industry

In the internal power distribution systems of buildings, hot-dip galvanized cable trays are commonly used in places with higher floors or complex spatial layouts, such as wiring inside ceilings and electrical pipeline installations in basements. They have strong corrosion resistance, can extend service life, and reduce maintenance costs.

2. Power systems

In the power supply systems of power plants and substations, hot-dip galvanized cable trays can carry a large amount of current transmission, possess good electrical conductivity and safety, effectively avoid the risk of fire caused by equipment failures, and facilitate inspection and maintenance.

3. Power facilities

3. Outdoor environments: The galvanized layer of hot-dip galvanized cable trays can effectively resist corrosion from wind, rain, ultraviolet rays, and moisture in the air, making them suitable for outdoor environments such as street lighting systems, highways, and railway lines.

4. Coastal areas

The air in coastal areas contains high levels of salt, and the anti-corrosion ability of hot-dip galvanized trays can effectively resist the erosion of marine climates, making them suitable for occasions such as seaports, docks, and marine engineering projects.

5. Industrial plants

In industrial environments such as chemical plants, oil refineries, and metallurgical plants, hot-dip galvanized trays can withstand chemical corrosion and humidity, protecting cables from corrosion and wear.

6. Commercial buildings

In commercial buildings such as office buildings, shopping malls, hospitals, etc., hot-dip galvanized cable trays are used for cable routing under ceilings, walls, or floors, ensuring the reliability and safety of the electrical system.

7. Outdoor cable routing

Suitable for outdoor environments such as power substations, outdoor communication base stations, railway/highway tunnels, etc., it can effectively withstand harsh weather conditions.

8. Humid and highly corrosive environments

In chemical plants, sewage treatment plants, offshore platforms, etc., where the environment is humid or highly corrosive, hot-dip galvanized cable trays provide good protection and extend the service life of cables.

9. Transportation infrastructure

In transportation facilities such as airports, stations, docks, etc., hot-dip galvanized cable trays are used to carry various power, communication, and monitoring cables, ensuring the efficient operation of the system.

10. Power transmission and distribution

During the cable laying process for high-voltage transmission lines and substations, hot-dip galvanized cable trays provide the necessary strength and stability, ensuring the safe transmission of cables.

11. Water Treatment Facilities

In sewage treatment plants and water purification plants, hot-dip galvanized cable trays are used to carry cables, resist the erosion of moisture and pollutants, and ensure the stability of the power system

12. Metallurgy and Mining

In metallurgical plants and mining operations, hot-dip galvanized cable trays can adapt to complex working environments, protecting cables from high temperatures and chemical substances.

13. Agricultural Facilities

In agricultural greenhouses and livestock farms, hot-dip galvanized cable trays are used for cable management, adapting to humid and corrosive environments, supporting automation equipment and monitoring systems.

14. Campuses and Public Facilities

In public facilities such as schools and hospitals, hot-dip galvanized cable trays are used for wiring of power and communication systems, ensuring the safety and reliable operation of the systems.
